Study of FIR filter design using window method:Bandpass and Bandstop
Instructions
Select FIR from Type
Select the sampling frequency (F
s
),centre frequency (F
c
)and centre frequency(F
c2
of the input signal.
Put the value of FIR filter order from FIR order tab,select filter type from Calculation sinc Bandpass or sinc Bandstop and attenuation(dB)
Click on the "Calculate" buttton to observe the Magnitude,Group delay,Impulse Response and simulation on plot
Note:
Make sure FIR order in range of 1 to 100
